TABLE 1
Inductance Percent Quality L,Q Freq. SRF DCR IDC
L(nH) Tolerance Min. (MHz) (MHz)Min. ( Ω) Max. (mA) Max.
MHSC-1608C-1N6□ 1.6 J,K 24 250 12500 0.030 700
MHSC-1608C-1N8□ 1.8 J,K 16 250 12500 0.045 700
MHSC-1608C-2N0□ 2.0 J,K 13 250 12500 0.080 700
MHSC-1608C-2N2□ 2.2 J,K 13 250 12500 0.150 700
MHSC-1608C-3N3□ 3.3 J,K 30 250 5900 0.045 700
MHSC-1608C-3N6□ 3.6 J,K 22 250 5900 0.063 700
MHSC-1608C-3N9□ 3.9 J,K 22 250 6900 0.080 700
MHSC-1608C-4N3□ 4.3 J,K 22 250 5900 0.063 700
MHSC-1608C-4N7□ 4.7 J,K 20 250 5800 0.085 700
MHSC-1608C-5N1□ 5.1 J,K 20 250 5700 0.115 700
MHSC-1608C-5N6□ 5.6 J,K 20 250 5800 0.160 700
MHSC-1608C-6N3□ 6.3 J,K 26 250 5700 0.115 700
MHSC-1608C-6N8□ 6.8 J,K 27 250 5800 0.125 700
MHSC-1608C-7N5□ 7.5 J,K 28 250 4800 0.115 700
MHSC-1608C-8N2□ 8.2 J,K 30 250 4700 0.125 700
MHSC-1608C-8N7□ 8.7 J,K 28 250 4600 0.109 700
MHSC-1608C-9N1□ 9.1 J,K 28 250 4600 0.120 700
MHSC-1608C-9N5□ 9.5 J,K 28 250 5400 0.145 700
MHSC-1608C-10N□ 10 G,J,K 31 250 4800 0.145 700
MHSC-1608C-11N□ 11 G,J,K 30 250 4000 0.145 700
MHSC-1608C-12N□ 12 G,J,K 35 250 4000 0.130 700
MHSC-1608C-13N□ 13 G,J,K 30 250 4000 0.130 700
MHSC-1608C-15N□ 15 G,J,K 35 250 4000 0.170 700
MHSC-1608C-16N□ 16 G,J,K 34 250 3300 0.170 700
MHSC-1608C-18N□ 18 G,J,K 35 250 3100 0.180 700
MHSC-1608C-19N□ 19 G,J,K 35 250 3000 0.190 700
MHSC-1608C-20N□ 20 G,J,K 38 250 3000 0.180 700
MHSC-1608C-22N□ 22 G,J,K 38 250 3000 0.190 700
MHSC-1608C-23N□ 23 G,J,K 38 250 2850 0.205 700
MHSC-1608C-24N□ 24 G,J,K 36 250 2650 0.205 700
MHSC-1608C-25N□ 25 G,J,K 38 250 2800 0.210 600
MHSC-1608C-27N□ 27 G,J,K 40 250 2800 0.220 600
MHSC-1608C-30N□ 30 G,J,K 37 250 2250 0.220 600
MHSC-1608C-33N□ 33 G,J,K 40 250 2300 0.220 600
MHSC-1608C-36N□ 36 G,J,K 37 250 2080 0.250 600
MHSC-1608C-39N□ 39 G,J,K 40 250 2200 0.260 600
MHSC-1608C-43N□ 43 G,J,K 38 250 2000 0.280 600
MHSC-1608C-47N□ 47 G,J,K 38 200 2000 0.280 600
MHSC-1608C-51N□ 51 G,J,K 38 200 2130 0.300 600
MHSC-1608C-56N□ 56 G,J,K 38 200 1900 0.310 600
MHSC-1608C-62N□ 62 G,J,K 37 200 1800 0.330 600
