2.2 DQ-4000 Mechanical Dimensions
130.0 mm (5.12”)
100.0 mm
(3.94”)
Figure 3: Mechanical Top Dimension
130.0 mm (5.12”)
30.8 mm
(1.21”)
Figure 4: Mechanical Front Dimension
