Operation
Starting the «Terminal Connection Manager»
3
l
7 LDCDP−11999 EN 3.0
3 Operation
3.1 Starting the «Terminal Connection Manager»
The operating system is located on the CF card of the Thin Client. When the Thin Client is
started, the operating system is loaded. The user interface, the Terminal Connection
Manager, appears.
Fig. 3−1 User interface
3.2 Terminal Connection Manager user interface (overview)
Register of the «Terminal Connection Manager»
Level 1 Level 2 Description
Connections Connect Thin Client to Terminal Server ^ 8
Configure Configure connection ^ 9
®[Add] WTS Connection
Wizard
Establish new connection with connection
wizard ^ 10
®[Edit] General
Set connection parameters (extended
configuration) ^ 12
Display Set display properties ^ 14
Local Resources Enable local resources of the Thin Client (drive,
printer, clipboard, etc.) ^ 15
Programs Define start application ^ 16
Experience Optimise network performance ^ 17
Advanced Set "Server authentication" ^ 18
F−Keys Configure function keys (F−keys) and software
keyboard ^ 19
General Configure network connection, calibrate
touchscreen, set system password, start
program, restart Thin Client ^ 20
