Signal−flow charts
How to read the signal−flow charts
4−2
l
EDSVF9383V−EXT EN 2.0
4.1
How to read the signal−flow charts
Symbol
Meaning
Signal connection in the Lenze setting
Analog input, can be freely connected to any analog output
Analog output
Digital input, can be freely connected to any digital output
Digital output
Input for speed signals, can be freely connected to any output for speed signals
Output for speed signals
Input for phase signals, can be freely connected to any output for phase signals
Output for phase signals
