Application examples
Accelerating and decelerating with constant time
3−3
l
EDSVF9383V−EXT EN 2.0
3.2
Accelerating and decelerating with constant time
This application is based on the basic configuration C0005 = 1000.
Example
A conveyor drive used together with other drives shall accelerate and decelerate in a constant time.
The setpoint for the conveying speed shall not influence the acceleration and deceleration time.
t
T
if
T
ir
n
Fig. 3−1
Accelerating and decelerating with constant time (C0104 = 1)
Setpoint 1
Setpoint 2
n
Speed
T
ir
Acceleration time
T
if
Deceleration time
