Scope of supply
Position Description Number
A ECSD Lxxx axis module 1
C Accessory kit with fixings 1
Mounting instructions 1
Drilling jig 1
L Application software: S = Speed & Torque P = Posi & Shaft
M = Motion A = Application
)
Note!
The ECSZA000X0B connector set must be ordered separately.
Connections and interfaces
Position Description Detailed
information
X23 Connections
l DC−bus voltage
l PE
^ 106
B LEDs: Status and fault display
X1 Automation interface (AIF) for
l Communication module
l Operating module (keypad XT)
x2 PE connection of AIF
X3 Analog input configuration ^ 118
X4 CAN connection
l MotionBus (CAN) / for ECSxA: System bus (CAN)
l Interface to the master control
^ 126
X14 CAN−AUXconnection
l System bus (CAN)
l PC interface/HMI for parameter setting and diagnostics
X6 Connections
l Low−voltage supply
l Digital inputs and outputs
l Analog input
l "Safe torque off" (formerly "safe standstill")
^ 113
^ 117
^ 118
^ 120
S1 DIP switch
l CAN node address
l CAN baud rate
X7 Resolver connection ^ 131
X8 Encoder connection
l Incremental encoder (TTL encoder)
l Sin/cos encoder
^ 132
X25 Brake control connection ^ 111
X24 Motor connection ^ 110
