Lenze E82ZAFSC010 User Manual
Page 40
Electrical installation
Wiring
EDK82ZAFSC−010 DE/EN/FR 6.0
40
l
H2_verdrahtung−INS_Klemmenbeleg
Use of plug connectors
(
Stop!
Observe the following to prevent any damage to plug connectors and
contacts:
ƒ
Only plug in/unplug if the controller is disconnected from the mains!
ƒ
First wire the plug connectors, then connect them!
ƒ
Also connect unassigned plug connectors.
Use of plug connector with spring connection
E82ZAFX013
