Mechanische installation – Lenze EPZ-10201 User Manual
Page 5
Mechanische Installation
EDK10201EZ3 DE/EN/FR 5.1
5
l
H1_MechINS−inst
4
Mechanische Installation
(
Stop!
Während der Installation Versorgungsspannung der Drive PLC abschalten!
Schutzkappe
0
von der Drive PLC [1a]
entfernen und aufbewahren.
A
1a
Stiftleisten
1
auf das Extension
Board [1b] einsetzen.
B
1b
Extension Board [1b] in die Drive PLC [1a]
einsetzen.
1a
1b
Klemmen des Extension Board belegen.
PES: HF−Schirmabschluss durch PE−Anbin-
dung
PES
PES
