1 Preface and general information
These Instructions
ƒ contain the most important technical data, describe the installation, handling and
commissioning of the extension board I.
ƒ are only valid
– for the extension board I with the type designation EPZ−10201
– together with the Mounting Instructions for the Drive PLC
Description
The extension board extends the Drive PLC by six digital intputs and six digital outputs.
Scope of application
Applicable together with the Drive PLC type EPL−10200−EI
Accessories
Items supplied
– two plug connectors, 2 x 13 pole each (already assembled at EPL−10201−EI)
– one 6−pole terminal strip for digital inputs (I9 ... I14)
– one 6−pole terminal strip for digital inputs (05 ... 010)
– one 6−pole terminal strip for output voltage (+024, VBr)
– one 6−pole terminal strip for GND (
^24)
