Technical data
General data and operating conditions
EDK10201EZ3 DE/EN/FR 5.1
12
l
H1_Daten−All_Data_Ext−board_I_en
3
Technical data
General data and operating conditions
Conformity
CE
Low−Voltage Directive (2006/95/EC)
Approvals
UL 508C
Underwriter Laboratories (File−No. E132659)
Power Conversion Equipment
DC supply voltage
Voltage
external +18 VDC −0 % ... +30 VDC +0 %
Current
max. 8 A
(at max. load of all outputs)
Climatic conditions
Class 3K3 to EN 50178
(without condensation, average relative humidity 85 %)
Temperature range
Transport
−25 °C ...
storage
−25 °C ...
Operation
0 °C ... +40 °C without power derating
+40 °C ... +55 °C with power derating
Power derating
of output currents for t
a
> +40 °C: 2.5 %/K
Vibration resistance
Resistant to acceleration up to 0.7 g
Permissible mounting
positions
in the Drive PLC on a plug−in−station for extension board
Insulation voltage to PE
50 V AC
Enclosure
IP 20
Digital inputs X4
Level
LOW (0 V ...
HIGH (+13 V ...
Input current
8 mA at 24 V
Digital outputs X3
Level
LOW (0 V ...
HIGH (+13 V ...
Load capacity
Output 05 ... 08: max. 1 A per output
Output 09, 010: max. 2 A per output
Dimensions
Height
145 mm (incl. terminal strips)
Width
72 mm
Depth
35 mm
