5 Electrical installation
Mains connection
EDK82ZWBRU DE/EN/FR 2.0
L
32
Danger!
z The cores with the colours BN, GN and BK and the contacts 1, 2 and 3
at the connection for the spring-operated brake feature hazardous
electrical voltages as long as the base unit is supplied with voltage.
z De-energize the basic unit before starting any work.
Stop!
Mains voltages > 440 V destroy the brake switch E82ZWBRU.
In systems with 500 V mains voltage, connect the brake switch only
between phase and protective earth conductor.
Mains voltage Brake voltage Connection Main voltage
-12-
One-way rectification Bridge rectification
Connection
diagram see
1/N/PE AC 230 V Operation not allowed DC 205 V E 33
3/PE AC 230 V Operation not allowed DC 205 V E 34
3/PE AC 400 V DC 180 V Operation not allowed E 35
3/N/PE AC 400 V Operation not allowed DC 205 V E 36
3/N/PE AC 500 V Operation not allowed DC 257 V
E 36
3/PE AC 500 V Operation not allowed Operation not allowed
