Potentiometer unit - Installation

EDK82ZBX020 3.0

- 2 -

Install and connect potentiometer unit

1. Break free opening M20 at the carrier housing or remove cover.
2. Bolt potentiometer unit into the opening from outside.

- Enclosure IP55 is maintained thanks to the preassembled seal.

3. Fix sticker to the carrier housing.
4. Connect potentiometer unit to the function module.
5.

Configure hardware and software of the motec for a setpoint range of 0 ... 5 V:
- Adapt the switch/jumper position at the function module.
- Adapt C0034.
