Commissioning
Setting options via switches
4
EDK82ZAFVC010 DE/EN/FR 2.0
57
l
H1inbet−reihenfolge einhalten
Setting options via switches
)
Note!
Settings via GDC, keypad or configuration software
Controller address and baud rate can be set by means of GDC, keypad or
configuration software.
For this, DIP switches S7 and S8 must be set to the ON position.
Settings via front switch
The Lenze setting of all switches is OFF.
The controller address and baud rate set via DIP switch will only be active after
restarting the controller.
Switch S9 is ineffective.
The following settings can be easily carried out via the front DIP switch of the function
module:
ƒ Software compatibility of E82ZAFVC / E82ZAFD function module with S10
ƒ Controller address with S1 − S6
ƒ Baud rate with S7 / S8
ON
1 6 2 7 4 3 8 5 9 10
ON
OFF
E82ZAFD005
Fig. 1 Software compatibility setting
Compatibility S10
E82ZAFVC0xx OFF
E82ZAFD
For the description of the
function module see the
E82ZAFD Mounting Instructions ON
