Parallel operation of AIF and FIF interfaces
11
l
89 EDS82ZAFPC010 EN 4.0
11.3 Parallel operation of AIF and FIF interfaces
)
Note!
The option of parallel operation ...
ƒ of a communication module (AIF) and a function module (FIF) exists for the
standard devices 8200 vector and Drive PLC.
ƒ of two function modules (FIF) exists for the standard devices 8200 motec,
Drive PLC and starttec.
Possible combinations
Function module on FIF
Communication module on AIF
Keypad E82ZBC
Keypad XT
EMZ9371BC
PROFIBUS−DP
EMF2133IB
System bus
CAN
EMF2171IB
EMF2172IB
CANopen
EMF2178IB
DeviceNet
EMF2179IB
Ethernet
PowerLink
EMF2191IB
Standard I/O PT E82ZAFSC010 ь ь ь ь ь ь
Application I/O PT E82ZAFAC010 ь ь ) ь ) ь ) ь ) ь )
PROFIBUS−DP E82ZAFPC010
ü x x x x x
PROFIBUS I/O E82ZAFPC201
Sys. bus CAN PT E82ZAFCC010
ь ь ь ь ь ь Sys. bus CAN PT E82ZAFCC210
Sys.−bus CAN−I/O RS PT E82ZAFCC100
CANopen PT E82ZAFUC010 ü x x x x x
DeviceNet PT E82ZAFVC010 ü x x x x x
INTERBUS PT E82ZAFIC010 ü x x x x x
LECOM−B PT E82ZAFLC010 ü x x x x x
AS interface PT E82ZAFFC010 ü x x x x x
Function module on FIF
Communication module on AIF
INTERBUS
EMF2113IB
LECOM−A/B
EMF2102IBC V001
LECOM−A
EMF2102IBC V004
LECOM−B
EMF2102IBC V002
LECOM−LI
EMF2102IBC V003
Standard I/O PT E82ZAFSC010 ь ь ь ь ь
Application I/O PT E82ZAFAC010 ь ) ь ) ь ) ь ) ь )
PROFIBUS−DP E82ZAFPC010
x ь ) ь ь ) ь )
PROFIBUS I/O E82ZAFPC201
Sys. bus CAN PT E82ZAFCC010
ь ь ь ь ь Sys. bus CAN PT E82ZAFCC210
Sys.−bus CAN−I/O RS PT E82ZAFCC100
CANopen PT E82ZAFUC010 x ь ) ь ь ) ь )
DeviceNet PT E82ZAFVC010 x ь ) ь ь ) ь )
INTERBUS PT E82ZAFIC010 x ь ) ь ь ) ь )
LECOM−B PT E82ZAFLC010 x ь ) ь ь ) ь )
AS interface PT E82ZAFFC010 x ь ) ь ь ) ь )
ь Combination possible, communication module can be supplied internally or externally
(keypad only internally)
ü Combination possible, communication module has to be supplied externally
x Combination not possible
