Codes
Communication−relevant Lenze codes
l
73
EDS82ZAFPC010 EN 4.0
C1511:
Configuration of process output data
Code
Subcode
Index
Possible settings
Data type
Lenze
Selection
C1511
23064
d
=
5A18
h
FIX32
1 (POW1)
17
see table below
2 (POW2)
3
3 (POW3)
4
4 (POW 4)
5
5 (POW 5)
6
6 (POW 6)
7
7 (POW 7)
8
8 (POW 8)
9
9 (POW 9)
10
10 (POW 10)
11
The process data output words (POW) of the master can be freely assigned to bit control
commands or setpoints of the controller via C1511.
Selection
Scaling
1
FIF control word 1 (FIF−CTRL1)
16 bits
2
FIF control word 2 (FIF−CTRL2)
16 bits
3
Setpoint 1 (NSET1−N1)
±24000
º ±480 Hz
4
Setpoint 2 (NSET1−N2)
±24000
º ±480 Hz
5
Additional setpoint (PCTRL1−NADD)
±24000
º ±480 Hz
6
Actual process controller value (PCTRL1−ACT)
±24000
º ±480 Hz
7
Process controller setpoint (PCTRL1−SET1)
±24000
º ±480 Hz
8
Reserved
9
Torque setpoint/torque limit value (MCTRL1−MSET)
2
14
º100 % rated motor torque
10
PWM voltage (MCTRL1−VOLT−ADD)
(
For special applications only.
^ System manual for 8200 vector
11
PWM angle (MCTRL1−PHI−ADD)
12
Reserved
13
FIF−IN.W1
16 bits or 0 ... 65535
14
FIF−IN.W2
16 bits or 0 ... 65535
15
FIF−IN.W3
0 ... 65535
16
FIF−IN.W4
0 ... 65535
17
DRIVECOM control word (DRIVECOM−CTRL)
16 bits
