Commissioning
Configuring the host system (master)
Adapting device controls
l
38
EDS82ZAFPC010 EN 4.0
6.3.1
Adapting device controls
ƒ
Lenze device control
– Set C1511/1 (POW1) = 1
ð FIF control word 1 (FIF−CTRL1)
– Set C1510/1 (PIW1) = 1
ð FIF status word 1 (FIF−STAT1)
ƒ
Device control via DRIVECOM
– Set C1511/1 (POW1) = 17
ð DRIVECOM control word (DRIVECOM−CTRL)
– Set C1510/1 (PIW1) = 18
ð DRIVECOM status word (DRIVECOM−STAT)
For detailed information about the configuration of process data, see chapter "Process
data transfer",
^ 43)
I
Tip!
Use overall consistency
ƒ
Please observe that the processing of consistent data varies between hosts.
This must be taken into account in the PROFIBUS application program.
ƒ
A detailed description of consistency can be found in the appendix (
¶ 86)
