Product description
Transport weights
3
EN
8 Lenze ¯ MA 12.0015 ¯ 1.0
Example
Example: g700 with motor
Made in
Germany
L Hans-Lenze-Straße 1
D-31855 Aerzen
GERMANY
3~MOT G70AP020MVCL1N MCS06C41-RS0B0-A11N-ST5S00N-R0SU
225 V~
270 Hz
1.3 A
max. 5.4 A
i = 5.0
0.25 kW
0.34 HP
IP 54
U 170 V in
M 3 Nm 2
M 15 Nm
2,GN
I.CL.F Ta 30°C KTY
C86: 1310
n 810 r/min 1eto
n 4050 r/min 2,th
Id.-Nr. 15696914
SN 156969141000017071234
Bremse
Brake
V A Nm
Geber
Feedback
RS
E210321 En60034
BEM34-132
Д123454678д936
3.3 Transport weights
g700 with MCA/MCS
Motor frame size
06 09 10 12 13 14 17 19
Gearbox size
g700−P20
< 3.0
g700−P44 < 4.5 < 7.0
g700−P130 < 6.0 < 11.0 < 10.0 < 13.0
g700−P260 < 13.0 < 18.0 < 17.0 < 25.0 < 22.0 < 31.0 < 36.0
g700−P800 < 37.0 < 13.0 < 51.0 < 48.0 < 70.0
Tab. 1 Weights in kg
