GPA mounting positions A, C, D
A
C
D
Nameplate (sample)
Hans-Lenze-Strasse 1
D-31855 Aerzen
http://www.Lenze.com
UL
File no.
N
Made in
Germany
3~MOT
GPA00-1SGCN-09FN38
330 V
1.2 kW
n
1eck
3750 min
-1
M
2
12 Nm !
n
2eck
938 min
-1
"
2.5 A #
1.6 HP $
c = 2.1 %
M
2GN
25 Nm &
i = 4
'
max. 5.9 A (
250 Hz )
Cooling type S00 I
CLP 150
000A
I.CL.F
IP 55
Fan data
Ta 30 °C
C86:1314
U
in
V
Item 00452320
Brake !!
Brake
V
A
Nm
Encoder
""
Feedback
RS 0
SN 15005432100065566 ##
IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII $$
Manufacturer
Lubricant type
Assembly plant
Position of system modules / mounting position
UL file no.
Insulation class
CE designation
Enclosure
Motor type
Fan data
Gearbox type
Ambient operating temperature
Rated voltage
Code for motor parameterisation
Motor driving power
Induced voltage
Input speed
ID number
!
Rated output torque of geared motor
!!
Brake data
"
Output speed
""
Encoder data
#
Rated current
##
Serial number
$
Motor driving power
$$
Bar code
%
Load capacity
&
Rated output torque of gearbox
'
Ratio
(
Maximum current
)
Rated frequency
I
Cooling type S00
