Technical data

Transport weights

3

11

BA 12.0030 EN 2.0

3.2

Transport weights

Geared servo motor

Drive size (square measure)

GPA

-

S GCN

06

09

12

14

19

GPA 00 - 1

< 6

< 10

GPA 01 - 1

< 8

< 12

< 19

GPA 02 - 1

< 15

< 22

< 37

GPA 03 - 1

< 30

< 45

< 59

GPA 04 - 1

< 75

GPA 05 - 1

< 90

GPA 00 - 2

< 7

GPA 01 - 2

< 9

< 13

GPA 02 - 2

< 17

< 24

GPA 03 - 2

< 36

< 51

GPA 04 - 2

< 84

GPA 05 - 2

< 112

Geared servo motor

Drive size (square measure)

GPA

-

A GCN

10

13

14

17

19

21

GPA 00 - 1

< 10

GPA 01 - 1

< 11

< 17

GPA 02 - 1

< 14

< 20

< 25

< 35

GPA 03 - 1

< 28

< 33

< 43

< 68

< 81

GPA 04 - 1

< 84

< 96

GPA 05 - 1

< 99

< 111

GPA 00 - 2

< 11

GPA 01 - 2

< 12

< 18

GPA 02 - 2

< 23

< 28

< 37

GPA 03 - 2

< 74

GPA 04 - 2

< 92

< 105

GPA 05 - 2

< 120

< 132

Tab. 1

Transport weight in [kg]
