Scope of supply
Pos. Description
- ETHERNET Powerlink hub
- Mounting Instructions
0Fig. 0Tab. 0
Connections
Pos. Connection Description
A1,
A2 ... A8
Ethernet RJ45 socket to EN 50173
B DC voltage supply Plug connector with spring connection, 4-pole
 PE M3 thread
Switch
Pos. Element Explanation
C Pushbutton switch Activates Rx/Tx crossing for connection A1:
z ON: MDIX
z OFF: MDI
Displays
Pos. Colour Status Description
OK Yellow On Device is supplied with voltage.
Rx1
...
Rx8
Yellow On
Activity
Connections A1 ... A8 send or receive data. Blinking
L/C1
...
L/C8
Green On Link
Connections A1 ... A8 are connected to the Ethernet
network.
Red On Collision
Connection between connections A1 ... A8 and the
Ethernet network is inhibited due to collision.
