Safety instructions
General safety information
1
EDK94AYAD DE/EN/FR/ES/IT 2.0
27

H1sic_EN-UL-Warn_Module_Temp_Fuse

Danger!
Danger to life through improper installation
Improper installation of the safety engineering systems can cause an
uncontrolled restart of the drives.
Possible consequences:
ƒ Death or severe injuries
Protective measures:
Total cable length between X82 and the connected components (e.g. sensors,
devices, etc.) > 3 m:
ƒ It is essential to shield the cable installed between X82 and the connected
components:
– Connect the shield at least to the shield support of the installation
backplane.
– If possible, connect the shield to the connected component as well.
Total cable length between X82 and the connected components (e.g. sensors,
devices, etc.) < 3 m:
ƒ Unshielded wiring is permitted.

Stop!
Before mounting/dismounting, switch off the supply voltage to prevent
electronic modules from damage.

Note!
The entry under code C00214 must correspond to the type of the safety
module plugged on. Otherwise, the controller signals the error: ”Wrong safety
module”.
