Lenze E94AYAD - SM300 - Manual (Page 21)

EDK94AYAD DE/EN/FR/ES/IT 2.0
21

M5Lieferumfang-SM300_disp_LED_statusDE
Displays
Pos. Colour State Description
MS Green
On Drive-based safety is initialised faultlessly.
Blinking
Drive-based safety is initialised faultlessly. Internal
communication to the standard device is not possible.
Off Drive-based safety is not initialised.
Acknowledgement is not possible.
EN Yellow
On Controller enabled
Off Non-safe display ”STO”
ME Red
On
System error:
z After a serious internal error, STO is activated.
z Can only be reset by switching the 24V supply.
Blinking
Error:
z After an internal error or an error at the safe
inputs, a standstill function is activated.
z The safety class is quit.
z Acknowledgement is possible.
Flashing
Fault:
z A monitoring function has responded and
activated a standstill function.
z The safety class is not quit.
z Acknowledgement is possible.
Off Error-free operation
PS Red
On
Error PROFIsafe:
z Communication is not possible.
z Acknowledgement is possible.
Blinking No valid PROFIsafe configuration
Off PROFIsafe is error-free.
DE Red On
The module is not accepted by the standard device
(see notes given in the documentation for the
standard device).
