3installazione meccanica – Lenze E94AZHY0026 User Manual
Page 90
Installazione meccanica
EDK94AZHY26 DE/EN/FR/ES/IT 1.1
90
l
H1_MechINS−MechInstall_Schr
Procedura di montaggio
1. Inserire il modulo di comando del freno motore nei morsetti
0 del modulo asse.
– Entrambi i dispositivi di fissaggio
1 devono scattare in posizione nelle apposite
scanalature
2 del modulo asse.
2. Verificare che il modulo di comando del freno motore sia correttamente montato.
