Lenze E94AZHY0026 User Manual
Page 18
Mechanische Installation
EDK94AZHY26 DE/EN/FR/ES/IT 1.1
18
l
H1_MechINS−MechInstall_Schr
Montageschritte
1. Motorbremsen−Ansteuerung auf die Klemmen
0 des Grundgerätes stecken.
– Beide Klammern
1 müssen in den Nuten 2 des Grundgerätes einrasten!
2. Motorbremsen−Ansteuerungsmodul auf festen Sitz kontrollieren.
