Lenze E94AZHY0026 User Manual
Page 36
Mechanical installation
EDK94AZHY26 DE/EN/FR/ES/IT 1.1
36
l
H1_MechINS−MechInstall_Schr
Installation steps
1. Plug the motor brake control module onto the terminals
0 of the standard device.
– Ensure that both clips
1 snap into the slots 2 of the standard device!
2. Check that the motor brake control module is securely connected.
