6 Electrical installation
Communication via the diagnostic interface (Servo Drives 9400)
EDKMF2181 DE/EN/FR/ES/IT 3.0
50

H1_E_INST-SteckerFederkraftAnschluss FKCT
Installation steps
Step Description Connection
(see graphic)
Additional
information
1. Connect the diagnostic interface to the Servo Drives
9400 (use prefabricated cable)   56
2. If it is not possible to use the internal modem, connect
an external modem.   59
3. Connect the controller to the CAN bus.  -
4. Connect the ModemCAN 2181 to the telephone network.   57
5. Connect the voltage supply to the plug connector.   60
