Operation
Controls and displays
Command Station CS 5070 DVI
7
l
45 BA_CS9000DVI EN 4.0
Pos. Designation Function
Standard mode Service mode
Switch on mode: Press " [ (F4)" for 4 s
Switch off mode: Press " [ (F4)" or wait for 35 s
0 Display Application−dependent
1 Status LEDs Power (green):
l Is ON when the supply voltage is present.
Fail (red):
l Is ON when a power supply failure has occurred.
l Is blinking when the screen signal is missing.
Status (yellow):
l Indicates access to a storage medium.
2 Function keys F1 ... F12: Send key code for Shift−F1 ...
Shift−F12 Tool: Application−dependent
+: Increase screen brightness
−: Reduce screen brightness
3 MF2 keys Standard function of a MF2 keyboard
