LIST8(ADF&TRAY)

REF No.

CODE

Q'TY

DESCRIPTION

RECOMMEND

REMARK

ORDER

TO BIUK

1

LE1525001

1

ADF UNIT(SP)

1

1-1

UG6609001

1

DOCUMENT SENSOR PCB

1-2

LG2014001

1

DOCUMENT SENSOR HARNESS

1-3

UF7026001

1

DOCUMENT FRONT SENSOR ACTUATOR

1-4

LE2008001

1

DOCUMENT REAR SENSOR ACTUATOR

1-5

LE2011001

1

COMPRESSION SPRING

1-6

LE2551001

1

RUBBER HOLDER A

1-7

UU2055001

1

SEPARATION RUBBER

1-8

LE2550001

1

SPRING PLATE A ASSY

1-9

LE2470001

1

ADF FILM

1-10

UF6116001

1

TAPTITE, PAN B M3X6

1-11

UF9009001

2

PRESSER ROLLER

1-12

LE2471001

1

PRESSURE ROLLER SHAFT

1-13

LE2472001

2

PRESSURE ROLLER SPRING

1-14

LE1215001

1

ADF MOTOR

1-15

LG2201001

1

ADF MOTOR HARNESS

1-16

0A4300605

2

SCREW, PAN (S/P WASHER) M3X6

1-17

LG2016001

1

GROUNDING WIRE

1-18

087310815

2

TAPTITE, CUP B M3X8

1-19

LE2026001

1

UPPER LF ROLLER (GRAY)

1-20

LE2029001

1

LOWER LF ROLLER( BLACK)

1-21

LE2028001

1

DOCUMENT EJECTION ROLLER

1-22

UF8105001

3

CONDUCTIVE BUSHING

1-23

UU7039001

4

LF ROLLER GEAR 27

1-24

LE2030001

1

WHITE ROLLER

1-25

LE2032001

2

WHITE ROLLER BUSHING

1-26

LE2033001

2

EXTENSION SPRING

1-27

LE2919001

1

DOCUMENT FEED ROLLER HOLDER ASSY

1-27-1

LE2037001

2

DOCUMENT FEED ROLLER (RUBBER)

1-28

UU1290001

4

CONDUCTIVE BUSHING

1-29

UU7505001

1

ANTI-STATIC BRUSH

1-30

087320616

3

TAPTITE, CUP S M3X6

1-31

UF0208001

1

ADF ARM

1-32

LE2048001

1

DOCUMENT EJECTION CHUTE ASSY

1-32-1

LE2582001

2

PINCH ROLLER, GRAY(1267)

1-32-2

UU2009001

2

PINCH ROLLER SPRING

1-33

LE2050001

1

ADF SIDE COVER F, GRAY(1495)

1-34

LE2051001

1

ADF SIDE COVER R, GRAY(1495)

1-35

LE2534001

1

ADF COVER ASSY, GRAY(1495)

1-36

087320816

2

TAPTITE, CUP S M3X8

2

UF8088001

1

PLASTIC RETAINING RING

3

LE2053001

2

ADF SUPPORT

4

087310816

2

TAPTITE, CUP B M3X8

5

LE2056001

1

DOCUMENT TRAY, GRAY(1495)

6

LE2487001

1

DOCUMENT SPONGE

7

LE3426001

1

DOCUMENT TRAY ASSY

8

LE2567001

2

HINGE A, BLACK

9

087311015

6

TAPTITE, CUP B M3X10

10

LE2777001

1

DOCUMENT SUPPORT, GRAY(1495)

11

087320816

1

TAPTITE, CUP S M3X8

12

LE2568001

2

HINGE HOLDER A

13

LE1568001

1

DOCUMENT TRAY REINFORCEMENT PLATE

14

UF6116001

1

TAPTITE, PAN B M3X6

MFC9760, MFC9860, MFC9880
