Instruction manual V 2.2 – 08/2005
Ordering information - knife holder CE
•
Knife holder CE for low-profile blades, assy.
•
Knife holder CE for high-profile blades, assy.
•
Pressure blade for high-profile blades
•
Pressure blade for low-profile blades
•
Anti-roll systems (metal change frame w/ glass insert)
•
Retrofit kit (metal change frame w/ glass insert and swivel arm)
•
Glass insert, 70 mm wide
•
Low-profile blades - 50 blades in dispenser
•
High-profile blades - 50 blades in dispenser
•
Leica Cryofect spray disinfectant
Technical specification - knife holder CN
-
Variable working distance between clamping jaws: 64 mm or 84 mm
-
Usable knife lengths: 12 cm - 22 cm
-
Knife height: min. 25 mm - max. 40.3 mm
-
Knife height adjustment: max. 16 mm
-
Clearance angle setting: 0 - 10, continuously adjustable
Ordering information - knife holder CN
•
Knife holder CN, assy.
•
Knife support bars – 13 cm and 15 cm long
•
Anti-roll system CN (metal change frame and glass insert)
•
Glass insert, 50 mm wide
•
Knives from 12 to 22 cm long
•
Leica Cryofect spray disinfectant
2.
Ordering information for knife holders CE / CN
