ES F
lybar
Weights & Strengths
Weights & Strengths
7
The ES Flybar System presents several configurations of system design product combinations for
suspension and rigging. Each component has to be factored into the total weight being suspended.
PART
WEIGHT
PER
UNIT
MAIN FRAME WITH PICK POINT HANG SUPPORT BAR
15 kg (33.07lbs)
VERTICAL
STEEL
ARM
BRACKET
1,6
kg
(3.52lbs)
FB
-
0002
ARM
1,62
kg
(3.57lbs)
ES
DOWNFILL
BRACKET
2,1
kg
(4.63lbs)
TOTAL WEIGHT OF ONE COMPLETE SYSTEM WITH 2 STEEL BARS
18,2 kg (40.13lbs)
TOTAL WEIGHT OF ONE COMPLETE SYSTEM WITH 4 STEEL BARS
21,44 kg (47.27lbs)
MAXIMUM SWL OF ONE COMPLETE SYSTEM WITH 2 STEEL BARS
500kg (1 102.3lbs)
MAXIMUM SWL OF ONE COMPLETE SYSTEM WITH 4 STEEL BARS
500kg (1 102.3lbs)
FOR CERTIFICATION OF FLYBAR COMPONENTS AND PINS PLEASE VISIT www.kv2audio.com
