PRODUCT INFORMATION
Specifications
Technology
IEEE Standards 802.3 10Base-T Ethernet, 802.3u 100Base-TX and 100Base-FX Fast Ethernet
802.3x Flow Control and Back Pressure, 802.1d Spanning Tree, 802.1w Rapid Spanning Tree
802.1p Class of Service, 802.1Q VLAN Tag
Processing Type Store and Forward
Flow Control Flow control on full duplex, Back Pressure on half duplex
MAC Address Table Size 2 KB
Memory Buffer 1 MB
Protocol CSMA/CD
Management
SNMP, Web GUI, and reset to factory default button
Transfer Rate 14,880 bps for Ethernet ports, 14,8800 for Fast Ethernet ports
Transfer Packet Size 64 bytes to 1522 bytes (with VLAN tag)
Packet throughput ability 1.49 Mbps @ 64 bytes
X-Ring 2 ports for X-Ring provide redundant backup with a recovery time below 300 MS.
Packet Filter 4 Selection Rules to filter combinations of Broadcast , Multicast, Unicast, and Unknown packets.
VLAN Port based and Tag. Up to 64 VLAN groups
Class of Service 4 priority queues per port
Quality of Service Port based, Tag based, or IPv4 Type of Service
IGMP IGMP v1 and Query mode. Up t o 256 groups
Clock Synchronization SNTP
Management Security IP Address
Port Mirror TX packet only or TX and RX packet
Firmware Update TFTP
DHCP DHCP Client Function to obtain addresses from DHCP server
Bandwidth Control Ingress Packet Filter rules and Egress Rate Control
Interface
RJ-45 Ports 10/100BaseT with auto negotiation, Full/Half Duplex, MDI/MDI-X
Fiber Ports 100Base FX, single-mode or multi-mode with ST or SC connectors
Port Indicators (each port) Green LED for Link / Activity and Yellow LED for Full Duplex / Collision
System Indicators Green LEDs for Power, Power 1, Power 2, and Master. Yellow LED for Fault.
Fiber Optics
Fiber Type Distance Wavelength Cable Output Optical Power Input Power Min
Multimode 2 KM 1310 nm 62.5/125 um -10 to 0 dBm < -28 dBm
Single Mode 30 KM 1310 nm 9/125 um -15 to -8 dBm < -34 dBm
Power SNMP MIB SNMP Trap
Input Voltage 12 to 48 VDC, dual source RFC 1213 MIBII Up to 3 Trap Stations
Current Consumption 0.8 A max. RFC 1493 Bridge MIB Cold Start
Input Connection Terminal Block RMON RFC 1757 Port link up
Relay Alarm 1A @ 24VDC RFC 2674 VLAN MIB Port link down
RFC 1643 Ethernet like MIB Authentication Failure
Mechanical RFC 1215 Trap MIB Power status
Enclosure IP30 Aluminum Case Private MIB for switch info Port Alarm
Mount 35 mm DIN or Panel Fault Alarm
Dimensions 2.3 x 5.7 x 4.3 in (5.8 x 14.5 x 10.9 cm) X-Ring
Environmental
CE Declaration of Conformity Operating Temperature -40 to 167 F (-40 to 75 C)
Manufacturer’s Name B&B Electronics Mfg CO Storage Temperature -40 to 185 F (-40 to 85 C)
Manufacturer’s 707 Dayton Road Operating Humidity 0 to 95% NC
Address PO Box 1040 MTBF EIR508-T 319175 hours
Ottawa, IL 61350 USA MTBF EIR508-2xx-T 315109 hours
Model Numbers EIR508-T, EIR508-2xx-T series Regulatory Approvals
Description Industrial Managed Switch EMI FCC Class A
Type Light Industrial ITE Equipment EN6100-4-2, -4-3, -4-4,
Application of Council Directive 89/336/EEC EN6100-4-5, -4-6
Standards EN55022 Safety EN60950
EN61000-4-2, -4-3, -4-4, -4-5 Free Fall IEC60068-2-32
EN61000-4-6, -4-8, -4-11, -4-12 Shock IEC60068-2-27
EN61000-6-2, -6-4 Vibration IEC60068-2-6
Michael J. Fahrion, Director of Engineering
