PREPARE THE HOOD

Unpack hood and check contents.
You should receive:

1 - Hood
1 - Decorative Flue Assembly
1 - Support Frame
1 - Duct Collar
1 - Parts Bag (B080810004) containing:

4 - Mounting Screws (6 x 70mm)
8 - Washers Ø 6.4mm
4 - Washers Ø 4.5mm
13 - Mounting Screws (3,9 x 9,5mm Pan Head)
4 - Nuts

1 - Installation Instructions
1 - Warranty Card

SUPPORT
FRAME

DECORATIVE
FLUE

13 MOUNTING
SCREWS

(3,9x9,5mm
Pan Head)

8 WASHERS
Ø6,4mm

4 WASHERS
Ø4,5mm

DUCT
COLLAR

4 NUTS

4 MOUNTING
SCREWS

(6x70mm)
