Kargo Master Pro II Platform Body (70030) - Manual (Page 5)

#
1
= Turn partially assembled rack upside down as shown. Cover entire
swedged joint surfaces with Silicone sealant, Then i nsert the swedged end of
each REAR leg , rope hooks facing outward, into the short tubes projecting
from the bottom of the SIDE BEAMS.
STEP 4
Silicone
05
A
Z
G
I
#
1
= Cover entire swedged joint surfaces with silicone sealant.
Slide FRONT CROSS BAR A into FRONT SIDE BEAMS 03 & 05 .
#
2
= BOLT TOGETHER with rubber washer
Z
, between TOP (small tube)
& SIDE RAIL (large tube), as shown, using bolt
G
& nut
I
.
The allen wrench is included in the package.
STEP 5
platform
#
1
= Slide REAR BAR on to
REAR SIDE BEAMS
D D
06
04 06
STEP 3
J
J
#
2
= Fully insert LOCK PINS J completely
to the bend of the pin.
#
2
= Attach CROSS BAR to siderails with bolts P, lock washers O and flat
washers H. Be sure to orient the CROSS BAR so that the mount
tabs are behind the cab guard, unless it is neccessary to
move the rear legs forward as described in STEP
1 before.
H
O
3 3
4 4
//
C
P
SIL
ICO
NE
SIL
ICO
NE
H
O
P
#3=
At each end of MIDDLE CROSS BAR start
BOLTS & WASHERS Slide BOLTS & WASHERS into
SLOTTED BRACKETS on the INSIDE CLAMP
PLATES , snug with an open end 3/4" wrench
(included in this package)
