Kargo Master Pro II Service Body (70020) - Manual (Page 5)

#1 = Cover entire swedge joints with GOOP and
join FRONT and REAR side channels together.
Be sure the connecting plates overlap and bolt
together with bolts Q, washers L and lock nuts M.
Q
M
L
GO
OP
SRV-BODY 12_1.1
#
2
= BOLT TOGETHER using G, H & I.
The allen wrench is included
in the package.REAR SIDE BEAMS
#
1
= Cover entire swedged joint surfaces with GOOP,
Slide FRONT CROSS BAR , into FRONT SIDE BEAMS A
03
05
#
1
= Slide REAR BAR on to
REAR SIDE BEAMS
J
#
2
= Fully insert LOCK PINS J
completely to the bend of the pin.
D
04
06
STEP 1
STEP 2
STEP 3
J
D
06
G
A
03
GOOP
I
H
