2009-05-11/00314545
Data Sheet 90.1190 (90.1109)
Page 4/4
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14,
36039 Fulda, Germany
Postal address:
36035 Fulda, Germany
Phone:
+49 661 6003-0
Fax:
+49 661 6003-607
E-mail:
Internet:
www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow - Essex CM20 2DY, UK
Phone: +44 1279 63 55 33
Fax:
+44 1279 63 52 62
E-mail:
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
8 Technology Boulevard
Canastota, NY 13032, USA
Phone:
315-697-JUMO
1-800-554-JUMO
Fax:
315-697-5867
E-mail:
Internet: www.jumo.us
Note: Bayonet sockets, Data Sheet 90.9725
Order details:
Push-in thermocouples with bayonet lock
(1) Basic version
901190/30
Push-in thermocouple, protection tube /
measuring tip (120°) stainless steel,
Mat. Ref. 1.4571, bayonet lock 12mm dia.
901190/40
Push-in thermocouple, protection tube
stainless steel, Mat. Ref. 1.4571,
measuring tip (120°) ceramic, KER 221,
bayonet lock 12mm dia.
(2) Operating temperature in °C / compensating cable
x x
832
0 to 200°C / silicone
x
835
0 to 260°C / metal braiding
x
836
0 to 260°C / PTFE
x
848
0 to 400°C / metal braiding
(3) Measuring insert
x x
1040
1 x Fe-Con J
x x
1042
1 x Fe-Con L
x x
1043
1 x NiCr-Ni K
x x
2042
2 x Fe-Con L
x x
2043
2 x NiCr-Ni K
(4) Protection tube diameter D in mm
x x
6
6mm
(5) Fitting length EL in mm
x
175
33 - 175mm
x
175
29 - 175mm
(6) Compensating cable end
x x
03
bare cable ends
x x
11
ferrules to DIN 46 228 Part 4 (standard)
x x
13
receptacle 6.3 to DIN 46 247
x x
80
multipole connector (please specify type in plain text)
(7) Compensating cable length AL in mm (500
≤ AL ≤500000)
x x
2500
2500mm (standard)
x x
...
please specify in plain text (500mm steps)
(8) Extra codes
x x
000
no extra code
x x
300
bayonet lock 14.5mm dia.
x x
302
bayonet lock 15mm dia.
x x
303
bayonet lock 16mm dia.
x x
309
uninsulated assembly (thermocouple welded to tip)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
Order code
-
-
-
-
-
-
/
,...
1
Order example
901190/30 -
836
- 1042 -
6
-
175
-
11
- 2500 /
000
1. List extra codes in sequence, separated by commas.
Stock versions
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
Sales No.
901190/10
848
1040
6
175
11
2500
000
90/00352190
901190/10
-
848
-
1040
-
8
-
175
-
11
-
2500
/
000
90/00371309
901190/10
-
848
-
1042
-
6
-
175
-
11
-
2500
/
000
90/00055784
901190/10
-
848
-
1042
-
8
-
175
-
11
-
2500
/
000
90/00055785
901190/20
-
848
-
1042
-
8
-
240
-
11
-
2500
/
309
90/00055792
901190/30
-
835
-
1042
-
6
-
175
-
13
-
2500
/
309
90/00055806
901190/40
-
848
-
1042
-
6
-
175
-
13
-
2500
/
000
90/00055804
