Order details:
Thermocouple insertion probes
(1) Basic type
901350/33
with multiple measurement points,
PTFE handle Ø 12mm, and PTFE cable
901350/63
with multiple measurement points,
PTFE handle Ø 15mm, and PTFE cable
901350/83
with multiple measurement points,
PEEK handle, and PTFE cable
901350/84
with multiple measurement points,
PEEK handle, and PTFE cable
(2) Operating temperature range in °C
x x x x 261 -100 ... +260°C
(3) Measurement insert (distributed along probe length EL)
x x x x 3043 3x NiCr-Ni Type K
x x x x 4043 4x NiCr-Ni Type K
x x 5043 5x NiCr-Ni Type K (only in combination with probe diameter 4.5mm)
(4) Probe diameter D in mm
x x x x 4 Ø 4mm
x x 4,5 Ø 4.5mm
(5) Insertion length EL in mm
x x x x 100 100mm (Standard)
x x x x 150 150mm
x x 200 200mm
(6) Insertion tip
x x x x 2 Concentric, angled at approx. 25°
x x x x 3 Oblique, angled at 45° (standard)
(7) Cable termination
x x x x 03 stripped wires
x x x x 11 Ferrules per DIN 46 228 Part 4 (Standard)
x x x x 80 Multi-pole connector (specify type in plain text)
(8) Cable length AL in mm (500 ≤ AL ≤ 500000)
x x x x 4000 4000mm (Standard)
x x x x ... Please specify in plain text (500mm steps)
(1) (2) (3) (4) (5) (6) (7) (8)
Order code - - - - - - -
Order example 901350/33 - 261 - 3043 - 4 - 100 - 2 - 03 - 4000
