2013-03-26/00592392

Data Sheet 606220

Page 2/3

JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14

36039 Fulda, Germany

Postal address:

36035 Fulda, Germany

Phone:

+49 661 6003-0

Fax:

+49 661 6003-607

E-mail:

[email protected]

Internet:

www.jumo.net

JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:

+44 1279 635262

E-mail:

[email protected]

Internet: www.jumo.co.uk

JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866

1-800-554-5866

Fax:

315-437-5860

E-mail:

[email protected]

Internet: www.jumousa.com

Technical data

Switching function

Case

Electrical data

Mounting / Application

Temperature controller (TR)

If the temperature on the temperature probe exceeds the setpoint value, the microswitch is activated by the
transmission mechanics and the electrical circuit is opened or closed. If the temperature falls below the
selected setpoint value (by the amount of the switching differential), the microswitch is reset to its initial posi-
tion.

Case

Sheet steel, zinc-plated

Protection type

IP 00 according to EN 60529

Switching socket

Plastic

Max. admissible ambient
temperature

For transport and storage: -20 to +55 °
When in use: max. +55 °C

Rated position (NL)

Any

Weight

Approx. 70 g

Capillary

1500 mm including 500 mm protective tubing as standard, min. bending radius of the capillary 5 mm
Material: stainless steel (CrNi)

Electrical contact

Snap-action switch with single-pole changeover contact

Switching capacity

Temperature controller (TR) On the N/C contact (contact deck 1-2):

AC 230 V +10 %, 16 A

On the N/O contact (contact deck 1-4):
AC 230 V +10 %, 0.5 A

Electrical connection

A 6.3-0.8 according to DIN 46244

Switching reliability

To ensure a high switching reliability, we recommend a minimum load of:

AC / DC = 24 V, 100 mA with silver contacts

Switching differential in °C

Approx. 5 °C +/-2 °C

Ambient temperature
influence

When the ambient temperature on the switching head and the capillary deviates – from the calibration ambient
temperature of +22 °C – a switching point offset occurs:
higher ambient temperature = lower switching point
lower ambient temperature = higher switching point

Switching point accuracy

Scale beginning

Scale end

±6 %

±4.5 %

in liquid media

operate only with a protection tube

in air

do not use protection tube
