Order details
Order code
( 1 )
Basic type
601530
Rod thermostat, series type STMA
( 2 )
Basic type extensions
01
STMA-1 temperature controller
TR with changeover contact
02
STMA-2 temperature monitor
TW with changeover contact
07
STMA-7 temperature limiter
TB with N/C contact
( 3 )
Control / limit value range
Range in °C
Immersion tube length in mm
020
0 to +40
300
021
0 to +50
250
015
-15 to +50
250
023
0 to +75
150
024
0 to +80
200 or 300
010
-80 to +100
200
017
-10 to +100
100
026
0 to +120
200
037
+15 to +120
150
043
+20 to +150
250
035
+5 to +160
100 or 150
028
0 to +200
250
044
+20 to +200
200
029
0 to +240
150
030
0 to +300
100
064
+50 to +300
200
( 4 )
Process connection
10
Plain cylindrical probe
Ø 9 mm
20
Screw-in thermowell
Ø 12 mm
54
Fixed screw-connection with hexagon (special model)
( 5 )
Thread of process connection
00
Without thread
13
External thread G 1/2
( 6 )
Material of process connection
46
CuZn (brass)
Only with process connection 10, 20, 54
20
CrNi (stainless steel)
Only with process connection 20
( 7 )
Insertion length "S“
(immersion tube length)
Note the dependency of the control range to the immersion
tube length!
100
100 mm
150
150 mm
200
200 mm
250
250 mm
300
300 mm
( 8 )
Extra codes
574
Microswitch with N/C contact, restart lock,
and additional signal contact (only for temperature limiter)
715
Loose screw-connection M 18 x 1 with locknut
764
Mounting element
( 1 )
( 2 )
( 3 )
( 4 )
( 5 )
( 6 )
( 7 )
( 8 )
Order code
601530
/
-
-
-
-
-
/
,
...
Order example
601530
/
02
-
26
-
20
-
13
-
46
-
200
/
000
a
a
State extra codes one after another, separated by commas.
,
...
