3 Installation
3.1 Installation site and climatic conditions
The installation site should be as free as possible from vibration.
Electromagnetic fields, such as those caused by motors, transformers etc.
should be avoided as far as possible.
The ambient temperature at the site can be 0 to 50°C, at a relative humidity of
75%, no condensation.
v Chapter 4.1 “Installation notes”
3.2 Mounting
Views
Panel cut-out
193
10
21
144
144
