Data Sheet 705021 Page 2/8
Description
Limit value monitoring
For each analog input, two separate alarms
(min/max alarm) can be activated; each alarm
has its own limit value. Alarm type, event text,
collective alarm, alarm suppression, and
alarm delay are configurable.
Analog inputs
The eight analog inputs are measuring inputs
for RTD temperature probes in 2-wire circuit.
Linearizations for Pt100, Pt500, and Pt1000
are saved. A measured value offset or a fine
adjustment can be carried out to compensate
for plant-specific deviations. Due to the mea-
suring circuit monitoring, a measuring range
that is too high or too low, probe/cable break,
and probe/cable short circuit are detected so
that the system is switched to an operational
safe status in the event of an error.
Digital input
In addition, a digital input DC 0/24 V is avail-
able. The signal status can be used in the sys-
tem in a flexible manner.
