Preparations
16
5. Preparations
5.1. Installation
Caution:
Securely fix the immersion circulator. The heater may not be in contact with the wall of
the bath tank. Keep a distance of at least 15 mm.
Units not adequately fixed may drop into the bath tank.
D a n g e r o f e l e c t r i c s h o c k !
First pull out the power plug to disconnect the unit from the power supply net. Then
take the immersion circulator out of the bath tank.
Make a service technician check the instrument before it is used again.
 Place the unit on an even surface on a pad made of non-
flammable material.
 The heating immersion circulator is mounted using a bath
attachment clamp (21) designed for bath wall thicknesses up
to 26 mm.
21
22
 Use the two sleeves (22) supplied with the unit to reduce the
immersion depth from 165 mm to 145 mm (see drawing).
 For use with glass vessels an upright stand rod, available as
optional accessory (order no. 8 970 022) may be attached.
5.2. Bath fluids
Caution:
Carefully read the safety data sheet of the bath fluid used, particularly with regard to
the fire point!
If a bath fluid with a fire point of
65 °C is used, only supervised operation is possible.
Water: The quality of water depends on local conditions.
 Due to the high concentration of lime, hard water is not suitable for temperature
control because it leads to calcification in the bath.
 Ferrous water can cause corrosion - even on stainless steel.
 Chloric water can cause pitting corrosion.
 Distilled and deionized water is unsuitable. Their special properties cause
corrosion in the bath, even in stainless steel.
