Operating instructions
10
Operating instructions
3.
OPERATING CONTROLS AND FUNCTIONAL ELEMENTS
FT400 FT200
FT 400
1
3
2
FT 400
1
3
2
Rear view
1 0
A
M
P
1 0
A
M
P
12
11
1
Mains switch, illuminated
2
Cooling control light
3
Clamp for immersion probe
7
Removable ventilation grid
8
Castor with locking lever
9
Tube connection - discharge
10
Tube connection - intake
11
Mains power cable with plug
12
Safety cutouts: Mains fuses 10 A
FD200
FD 200
1
9
10
