B&B Electronics Zlinx 485 User Manual
Page 40
Product Specifications
Manual Documentation Number: Zlinx485m-1808
www.bb-elec.com
www.bb-europe.com
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
A
A
:
:
P
P
r
r
o
o
d
d
u
u
c
c
t
t
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Base Module Models:
ZZ-NA-485, ZZ-NB-485, ZZ-NC-485, ZZ-ND-485
Expansion Module Models: ZZ-4AI, ZZ-4AO, ZZ-2AI2AO, ZZ-8D0-T, ZZ-8D0-T1, ZZ8DDO-R, ZZ-4DI4DO-DCT, ZZ-
4DI4DO-DCT1, ZZ4RTD1
Quick Start guide: Paper copy, PDF available on enclosed CD-ROM disc
Manual: Available on enclosed CD-ROM disc, and on B&B website
CD-ROM disc: Zlinx 485 Manager
PDF of Zlinx 485 User Manual
PDF of Quick Start guide
Operating Systems supported: Windows ME/98/2000/XP
Dimensions: 1.15 x 3.65 x 5 in (2.92 x 9.27x 12.7 cm)
Expansion Feature: 1 base module and up to 6 expansion modules
Power Indicator: Red LED
Data Indicator: Green LED (blinks with TD or RD data traffic, Off = no data traffic)
Bus Indicator: Green LED (blinks with TD or RD bus traffic, Off = no bus traffic)
Data Error Indicator: Data & Bus LED’s blink alternately
Modbus Connectors: Removable screw terminal (5 position) block, 3.5 mm spacing
Serial Connectors
Side connector: RF-45 female, RS-232
Top connector: Removable screw terminal block (5) with screw down clamping
Interface Lines Supported: RS-232
RS-422/485 RDB+, RDA-, TDB+, TDA-
Serial Data Rates: 1200, 2400, 3600, 4800, 9600, 19200, 38400, 57600, 115200, 230400 bps
I/O Connectors: Removable screw terminal (2, 4 or 8 position) block, 3.5 mm spacing
Digital Inputs
Voltage Range: 0 to 48 VDC
Low Voltage (0): 0.8 V maximum
High Voltage (1): 4.0 V minimum
Pull up Resistor (NPN Input): 130K
Pull down Resistor (PNP Input) 10K
