12. Technical specifications
Input data:
Measuring ranges:
0 .. 100 °C / 32 .. 212 °F
Output data:
Accuracy (display, analogue output)
≤ ±1.0 % of the measuring range
Repeatability: ≤ ±0.25 % of the measuring range
Temperature drift in the ambient temperature
range: ≤ ±0.03 %/°C / ≤ ±0.054 %/°F zero point
≤ ±0.03 %/°C / ≤ ±0.054 %/°F range
Analogue output:
Signal:
4 .. 20 mA, ohmic resistance
≤ 400 Ω
0 .. 10 V, ohmic resistance
≥ 2 KΩ
Switching outputs:
Type:
4 relays with change-over contacts in 2
groups (common supply of each group
connected)
Switching voltage: 0.1 .. 250 VAC / VDC
Switching current: 0.009 .. 2 A
Switching capacity: 400 VA, 50 W
(for inductive load, use varistors)
Life expectancy of contacts:
≥ 20 million min. load
≥ 1 million max. load
Reaction time (without switching delay): approx. 20 ms
Setting range of switching points 1.5 .. 100 % of the measuring range
Setting range of hystereses / switch-back
points 1 .. 99 % of the measuring range
Ambient conditions:
Ambient temperature range:
-25 .. +60 °C / -13 .. +140 °F
Storage temperature range: -40 .. +80 °C / -40 .. +176 °F
mark: EN 50081-1, EN 50081-2
EN 50082-1, EN 50082-2
Vibration resistance: approx. 5 g
Shock resistance: approx. 10 g
Other data:
Sensor connection:
5-pole Binder connector, series 681
Electrical connection: 14-pole, terminal strip,
connection cross-section max. 1.5 mm²
Supply voltage: 22 .. 32 VDC, residual ripple
≤10%
Current consumption: approx. 200 mA
Display: 4-digit 7-segment LED display, red,
height of digits 13 mm
Safety type: IP 65
Weight: approx. 800 g
Technical specifications - Accessories
TFP 100
Temperature range of medium (for TFP 100):
-40 .. +125 °C / -40 .. +257°F
