User manual EDS 8000 US Page 5
Status 09.09.2009 HYDAC ELECTRONIC GMBH Part No. 669820
Reading the digital display
Description
Representation on
7-segment display
ASCII representation
Switch point, output 1 sp1 SP1
Switch-back point, output 1 rp1 RP1
Switch point, output 2 sp2 SP2
Switch-back point, output 2
rp2
RP2
Pressure window upper value, output 1
fk1
FH1
Pressure window lower value, output 1
fl1
FL1
Pressure window upper value, output 2 fk2 FH2
Pressure window lower value, output 2 fl2 FL2
Extended functions ef EF
Reset res RES
Switch delay time, output 1
ds1
dS1
Switch delay time, output 2
ds2
dS2
Switch-back delay time, output 1 dr1 dR1
Switch-back delay time, output 2 dr2 dR2
Output 1 ov1 Ou1
Output 2 ov2 Ou2
Normally open when hysteresis
function is active
kno HNO
Normally open when window function
is active
fno FNO
Normally closed when hysteresis
function is active
knc HNC
Normally closed when window function
is active
fnc FNC
Unit conversion
uni
Uni
Units in bar bar Bar
Units in MPa mpa MPa
Units in psi psi psi
Maximum value ki HI
Error indication
err
ERR
Delete
---
---
Extended functions ef EF
Yes yes Yes
No no No
Version Uer Ver
