9. Technical specifications
Input data::
Measuring ranges:
-14 .. 75 / 0..150, 1000, 3000, 6000, 9000 psi
Overload pressures: 150 % FS, max. 13000 psi
Burst pressure: 300 % FS
Output data:
Accuracy (display, analogue output)
±1.0 % FS max.
Repeatability: ±0.5 % FS max.
Temperature drift: zero point max.
range max.
±0.016 %/°F ( ±0.03 %/°C)
±0.016 %/°F ( ±0.03 %/°C)
Analogue output: 4 .. 20 mA, ohmic resistance 400
Switching outputs:
Type:
PNP transistor output
Switching current: max. 1.2 A
Switching cycles: 100 million
Reaction time: approx. 10 ms
Ambient conditions:
Temperature range of medium:
-13 .. 176 °F (-25 .. + 80 °C)
Ambient temperature range: -13 .. 176 °F (-25 .. + 80 °C)
Storage temperature range: -40 .. 176 °F (-40 .. + 80 °C)
Nominal temperature range: 14 .. 158 °F (-10 .. + 70 °C)
- mark: EN 50081-1 and -2, EN 50082-1 and -2
Vibration resistance: approx. 10 g / 0..500 Hz
Shock resistance: approx. 50 g / 1ms
Other data:
Supply voltage:
20 .. 32 VDC
Electrical connection: plug M12x1
Current consumption: approx. 100 mA (without switching output)
Safety type: IP 65
Hydraulic connection: 7/16 SAE 4 female
Parts in contact with medium: stainless steel
Material of housing: tube: stainless steel, keypad housing: PA6.6 Gf30
Display: 4-digit, 7-segment LED, red
Weight: approx. 300 g
Note: FS (Full Scale) = relative to the full measuring range
