PARTS
Number Description
Quantity
Per
Assembly Comments
55 PARTS & REPAIR MANUAL
* 1 – Textile (W,V,X,Z,L,P,U,D,E) 2 – Textile/Mesh Color 3 – Frame Color (B, V, L, A, P) 4 – Mesh (M,C, T) 5 – Arm Pad Color (S, B)
Refer to Price Guide for all Cushion Pricing.
Note: All part numbers and prices are for single units only.
Unit
Price
¦
P
A
R
T
S
DWCB 3 4 2 2 Mesh Backrest Assembly 1 See Price Guide
DWCS 3 4 2 2 Mesh Seat Assembly 1 See Price Guide
DWCSM 3 1 2 2 2 Textile Covered Seat Assembly 1 See Price Guide
DWFD 3 5 Fixed Duron Arm Pads 1 See Price Guide
DWFDM 1 2 2 2 Fixed Duron Arm Pads W/ Textile Cover 1 See Price Guide
DWAD 3 5 Adjustable Duron Arm Pads 1 See Price Guide
DWADM 1 2 2 2 Adjustable Duron Arm Pads W/ Textile Cover 1 See Price Guide
DWKFD 3 5 Fixed Duron Arms 1 See Price Guide
DWKFDM 3 1 2 2 2 Fixed Duron Arms W/ Textile Cover 1 See Price Guide
DWKAD 3 5 Adjustable Duron Arms 1 See Price Guide
DWKADM 3 1 2 2 2 Adjustable Duron Arms W/ Textile Cover 1 See Price Guide
3800100106BL Pivot Pin - Black 2 $3.00
3800100106DG Pivot Pin - Gray 2 $3.00
3800100106WH Pivot Pin - White 2 $3.00
3800100113NL Back Assist Spring 2 $1.15
3800100064BL Arm Screw - Black 4 $2.90
3800100064DG Arm Screw - Gray 4 $2.90
3800100064WH Arm Screw - White 4 $2.90
3800100038NL Pivot Tube 4 $3.80
3800101008BL Support Frame - Black 1 $105.00
3800101008DG Support Frame - Gray 1 $105.00
3800101008WH Support Frame - White 1 $105.00
3800100001BL Base - Black 1 $60.00
3800100001DG Base - Gray 1 $60.00
3800100001WH Base - White 1 $60.00
3800100090BL Hard Caster - Black 5 $5.00
3800100090DG Hard Caster - Gray 5 $5.00
3800100090WC Hard Caster - White 5 $5.00
3800100091BL Soft Caster - Black 5 $7.00
3800100091DG Soft Caster - Gray 5 $7.00
3800100091WC Soft Caster - White 5 $7.00
Cylinder See Page 37 (Liberty) 1
Foot Ring See Page 37 (Liberty) 1
