P
A
R
T
S
Unit
Price
¦
PARTS
Number Description
Quantity
Per
Assembly Comments
33 PARTS & REPAIR MANUAL
1
1
1
1
1
1
1
1
3
3
3
3
3
3
6
$100.00
$100.00
$56.90
$10.00
$50.00
$50.00
$10.00
$10.00
$8.00
$2.00
$0.50
$0.10
$0.30
For use with saddles that have
sustained damage to the hub.
Includes everything but the
base, cylinder and cushion
See Seating Price Guide
See Seating Price Guide
* 1 – Textile (W,V,D,U,X,Z,L,P), 2 – Cushion Color, 3 – Frame/Cushion Shell Color (G = Graphite, T = Titanium)
Refer to Price Guide for all Cushion Pricing.
¦
Note: All part numbers and prices are for single units only.
F-SADDLE-HUB ASSY Complete Seat Assembly
F-PONY-HUB ASSY Complete Seat Assembly
3000511100 Hub
3500610000 Slider
L 1 2 2 2 * Saddle Cushion, Foam
LP 1 2 2 2 * Pony Saddle Cushion, Foam
3800090003GR Saddle Shell, Graphite
3800090025GR Pony Saddle Shell, Graphite
3800090007BL Actuator Rod
3800090028BL Pony Saddle Actuator Rod
8500810000 1-1/2" Soft Touch Knob
2001110000 Pin Actuator for Stool
3800050012BL #14x1.5" Plastite Torx button hd
0401510000 3/16" Push on Retaining Ring
3800050195BL Screw, Torx pan head, Hi-Lo #10x1/2
