PARTS
Number Description
Quantity
Per
Assembly Comments
49
®
PARTS & REPAIR MANUAL
* 1 – Textile (W,V,X,Z,L,P,U,D,E) 2 – Textile/Mesh Color 3 – Frame Color (B, V, L, A, P) 4 – Mesh (M,C, T) 5 – Arm Pad Color (S, B)
Refer to Price Guide for all Cushion Pricing.
Note: All part numbers and prices are for single units only.
Unit
Price
¦
P
A
R
T
S
3800380130BL Adjustable Arm, Right, Black 1
3800380162BL Adjustable Arm, Left, Black 1
3800380130SL Adjustable Arm, Right, Silver 1
3800380162SL Adjustable Arm, Left, Silver 1
3800380130AL Adjustable Arm, Right, Polished w/ Black Trim 1
3800380162AL Adjustable Arm, Left, Polished w/ Black Trim 1
3800380130PL Adjustable Arm, Right, Polished w/ Silver Trim 1
3800380162PL Adjustable Arm, Left, Polished w/ Silver Trim 1
LGV Height-Adj. Gel Arm Pads w/ Xanium Cover 1 See Seating Price Guide
LGVM 1 2 2 2 Height-Adj. Gel Arm Pads w/ Matching Textile 1 See Seating Price Guide
LDV 5 Height-Adj. Duron Arm Pads 1 See Seating Price Guide
LDVM 1 2 2 2 Height-Adj. Gel Arm Pads w/ Matching Textile 1 See Seating Price Guide
3800380155BL Adjustable Arm, Pivot Cover, Right, Black 1
3800380156BL Adjustable Arm, Pivot Cover, Left, Black 1
3800380155SL Adjustable Arm, Pivot Cover, Right, Silver 1
3800380156SL Adjustable Arm, Pivot Cover, Left, Silver 1
3800380160NL #6x5/8 Phillips Pan Hd. Plastite 4
3800380111BL Adjustable Arm, Lower Cover, Right, Black 1
3800380111SL Adjustable Arm, Lower Cover, Right, Silver 1
3800380123BL Adjustable Arm, Lower Cover, Left, Black 1
3800380123SL Adjustable Arm, Lower Cover, Left, Silver 1
