EXPLODED PRODUCT VIEW, PARTS & ORDERING INFORMATION
*** Item not shown.
∆
Denotes parts included in the Service Kit.
Parts listed are for stock models. For specific OEM models, please consult the factory.
When corresponding or ordering parts, please give complete model and serial numbers.
REF DESCRIPTION QTY 55R720-101
1 ∆ PISTON CUP 2 AL121
2 RETAINER PLATE (VACUUM) 1 AL119
3 RETAINER PLATE (PRESSURE) 1 AL120
4 CYLINDER (VACUUM) 1 AL133V
5 CYLINDER (PRESSURE) 1 AL133P
6 ∆ O-RING 2 AL123
7 ∆ VALVE 4 AL126
8 ∆ VALVE PLATE 2 AT353A
9 O-RING GASKET 2 AL113
10
∆
PUMP HEAD 2 AT154
*** SERVICE KIT 1 K531
